Hazloc Stainless Steel Junction Box - 20" x 16" x 10" External Dims - C1D2, ATEX/IECEx - N4X, IP66
Hazloc Stainless Steel Junction Box - 20" x 16" x 10" External Dims - C1D2, ATEX/IECEx - N4X, IP66
| EPL-AEH-SS-20.16.10-N4X-BP ATEX Rated Junction Box | Ratings |
| Listing: United States, Canada, European Union, International | Class I, Division 2 Groups A,B,C,D |
| Internal Dimensions: 18.93"-H x 14.93"-W x 9.74"-D | Class I, Zones 1&2 Groups IIA,IIB,IIC |
| External Dimensions: 20"-H x 16"-W x 10"-D | Class II, Groups E,F,G |
| Distance Between Mounting Lugs: 14.69", 18.69", 17.63", 21.63"- Depending on Direction of Lug | Class III |
| Weight: 32 lbs | ATEX/IECEx Rated |
| Maximum Power: 26W | Ex e IIC Gb, Ex i IIC Gb |
| Mechanical Resistance: Impact Energy 7 Nm | Ex tb IIIC Db IP66 |
| Ambient Temp: -20°C to +40°C | Ex tb / Zone 21&22 AEx tb IIIC |
| Operating Temp: -20°C to +85°C | T80C /T100C/T130C Db IP66 |
| Cover Type: Hinge - Concealed, Removable Pins | Type 3, 4 & 4X |
| External Ground Lug: Included | Â |
| Backplate: Included | |
| Body and Cover Material: 316 Stainless Steel | |
| Gasket Material: One-piece High Temp Closed Cell Silicone | |
| Mounting: Surface or Wall | |
| Maximum Conduit/Gland Openings: 4" NPT (M100) | |
| Custom Options (Not Included): Panel ID Tag 316 SS, Tamperproof Latches, Key Latches, Copper Ground/Earth Bars, Hubs (Size and Location), Glands, Backplate, Terminals and More | |
| The EPL-AEH-SS-20.16.10-N4X-BP from Larson Electronics is a Hazardous Location Stainless Steel Junction Box that provides operators with a rugged enclosure that is designed to hold and protect equipment in flammable environments. This IP66-rated enclosure is ideal for Class I, Division 2 sites, as well as ATEX/IECEx-rated environments and indoor or outdoor applications where flammable vapors, gases, or dusts exist or stand the potential to exist. *PLEASE NOTE: ANY FREE SHIPPING OFFERS DO NOT APPLY TO EXPLOSION PROOF ENCLOSURES* The EPL-AEH-SS-20.16.10-N4X-BP offers protection for equipment in Class I, Division 2 and ATEX/IECEx rated combustible sites. Equipped with a hinged cover that is concealed and contains removable pins, this junction box measures 20" x 16" x 10" (external dimensions). Internal dimension measurements include 18.93" x 14.93" x 9.74". The enclosure accepts a maximum power of 26 watts and includes an external ground lug and backplate. The heavy-duty junction box is constructed of 316 stainless steel, with 316 stainless steel hardware and a one-piece, high temperature silicone gasket. A NEMA 4X waterproof rating indicates that the hazardous location enclosure provides a degree of protection against the ingress of dust, dirt and fibers as well as resistance against the harmful and corrosive effects of water spray, sleet, snow and rain. This level of protection also prevents damage caused by the formation of ice. The IP66 rating associated with the enclosure offers complete dust tight protection and deters damage caused by powerful jets (12.5 mm nozzle) from all angles. The hazardous location stainless steel junction boxes in this series can be customized with the following components: panel ID (316 stainless steel), tamperproof latches, key latches, copper ground/earth bars, hubs (quantity/location), glands, backplates, terminals and more. Hubs: This enclosure features a maximum conduit opening of 4" NPT (M100). Mounting: The EPL-AEH-SS-20.16.10-N4X-BP is compatible with surface or wall mounting applications via four bi-directional removal mounting lugs at the back of the unit. Applications: Offshore rigs, sewage and wastewater treatment plants, coal plants, gas facilities, paper mills, grain facilities, marine sites, docks, pumping stations, food processing and any other sites where a hazardous location or ATEX-rated enclosure is needed. Â |
