100A Explosion Proof Manual Transfer Switch - Class I and II, Div 1 & 2 - 3P - (3) 2" Hubs

LARSON ELECTRONICSSKU: PL3-EPNFDS-MTS-100A-3P-M1
filler

Precio:
Precio de venta$10,084.00

Descripción

Specifications / Additional Information
EPNFDS-MTS-100A-3P-M1 Explosion Proof Manual Transfer Switch Features/Ratings
Listing: 1NRTL Listed for United States and Canada Class I Division 1 & 2 Groups B, C & D
Dimensions: 14.3125" x 12.3125" x 8.625" Class I Zones 1 & 2 Groups llB+ H2 & llA
Weight: 48 lb Class II Division 1 & 2 Groups E, F & G
Configuration: 3-Pole Divisions 1 & 2
Voltage Rating: 600V AC Max NRTL Listed to UL 1203
Amps: 100A NRTL Listed to CSA C22.2 No. 30, 25
Fusible: No NEMA 3, 4, 4X, 7 (B, C, D), 9 (E, F, G)
Materials: Copper-free Aluminum
Hardware Materials: Stainless Steel (Hinges, Cover Bolts) Special Orders - Requirements
Mounting: Surface Mount
Hub Sizes: (3) 2" NPT
Hub Qty: 3
Hub Locations: South Side of Enclosure
Conduit: Operator Provided
*All grounding shall comply with state and local codes and meet the minimum requirements of the National Electronic Code section 250*
' Product Overview '
Made in the USA The Larson Electronics EPNFDS-MTS-100A-3P-M1 Explosion Proof 100 amp Manual Transfer Switch provides operators with a Class I and II, Divisions 1 and 2 copper-free aluminum enclosure for overcurrent and short circuit protection of service entrances, feeder or branch circuits, lighting, heating, appliances and motor circuits. This 600V rated explosion proof manual transfer switch has a 3-pole configuration. *PLEASE NOTE: ANY FREE SHIPPING OFFERS DO NOT APPLY TO EXPLOSION PROOF ENCLOSURES* The EPNFDS-MTS-100A-3P-M1 explosion proof manual transfer switch is made of copper-free aluminum and features a rectangular bolted cover design for uniform and attractive installations. The external on/off lever can be locked into the "off" position with room for up to three padlocks for superior security. The internal circuit breaker handle mechanism is a sliding plate type mounted to the cover. The circuit breaker is trip free of the external handle mechanism. This unit is rated for NEMA 4X environments, making it ideal for indoor and extreme outdoor applications. Operators may access three, 2" NPT hubs at the south side of the enclosure. Applications: Petroleum refineries, chemical and petrochemical plants, storage areas, and other processing facilities where hazardous substances are handled or stored.
