Explosion Proof Plug - C1D1, C2D1 - 60 Amps - 3 Wire, 4 Pole - Pin/Sleeve

LARSON ELECTRONICSSKU: PL3-EPP-3W4P-60A
filler

Precio:
Precio de venta$562.00

Descripción

Specifications / Additional Information
EPP-3W4P-60A Explosion Proof Plug Ratings
Unit Type: Explosion Proof Pin/Sleeve Plug Class I, Div. 1&2 Groups B,C,D
Dimensions: 8.8125" -L x 3.375" -D Class I, Zones 1&2 Groups IIB+H2,IIA
Weight: - Class II, Div. 1&2 Groups F&G
Voltage: 600V AC/250V DC 50-400 Hz Class lll
Amps: 60A Rated NEMA 3, 4, 4X
Configuration: 3-Wire 4-Pole
Grounding Style: Style II
Materials: Copper-free Aluminum
Grommet Range: .65" - 1.50"
Mate (Receptacle): EPO-3W4P-60A-ICB Intl: 1-214-616-6180
Fax: 1-903-498-3364
  E-mail:
' Product Overview '
The Larson Electronics EPP-3W4P-60A Explosion Proof Plug provides secure connections with compatible explosion proof equipment in combustible facilities. The 3-wire, 4-pole unit is rated at 60 amps and is constructed of copper-free aluminum. This pin/sleeve explosion proof plug mates with our EPO-3W4P-60A-ICB receptacle. The EPP-3W4P-60A is suitable for completing electrical connections in flammable work sites and hazardous locations. This 60-amp rated explosion proof accessory is designed to be used with our EPO-3W4P-60A-ICB receptacle (mate). The accessory features a 3-wire, 4-pole configuration and Style II grounding. Constructed of copper-free aluminum, the pin/sleeve unit offers compatibility with 600V AC/250V DC 50-400 Hz. Suggested Applications: Manufacturing, Industrial, Warehouse, Lighting, Motor-Generator  Sets, Compressors, Wet areas or Locations Where Petrochemical Vapors are Present.
