Explosion Proof Push Button Stop/Reset Switch - Class I, II, III - (2 Sets) Contacts

LARSON ELECTRONICSSKU: PL3-EPS-2XPB-SG-M2
filler

Precio:
Precio de venta$1,544.00
 Más opciones de pago

Descripción

Specifications / Additional Information
EPS-2XPB-SG-M2 Explosion Proof Push Button Stop/Reset Switch Ratings/Approvals
Listing: NRTL Listed for United States & Canada Class I, Divisions 1 & 2, Groups C,D
Dimensions: 5.1"L x 5.875"W x 6.25"H Class II, Zones 1 & 2, Groups IIA
Weight: - Class II, Divisions 1&2, Groups E,F,G
Voltage Rating: 250 Volts Max Class III
Current Rating: 10 Amps Max @ 250V NEMA 3, 7 (C,D), 9 (E,F,G)
Switch Type: Push Button Labeled Push Buttons
No. of Switches: (2) - (1) Green, (1) Red
Switch Labels: Reset/Stop
Contacts: (2 Sets) - (2) NO for Green (Reset) PB, (2) NC for Red (Stop) PB Special Orders - Requirements
Materials: Box: Malleable Aluminum/Switch Cover Cast Copper Free Aluminum Alloy
Insulation: Integral Bushings in Conductor Openings
Mounting: External Mounting Lugs on Body
Configuration: Feed Thru or Dead End
Hub: 1/2" or 3/4" NPT
' Product Overview '
The EPS-2XPB-SG-M2 from Larson Electronics is an Explosion Proof Push Button Stop/Reset Switch that is Class I, II and III rated for use in combustible environments. Featuring two labeled push buttons for Stop and Reset, the unit contains two sets of contacts. This explosion proof switch provides manual starting and resetting of small motors. The EPS-2XPB-SG-M2 is rated for 10 amps at 250 Volts. This unit contains two clearly labeled push buttons: one green/reset and one red/stop. The green push button is equipped with two NO contacts and the red push button is equipped with two NC contacts. The switch is enclosed in a cast aluminum device box, and the faceplate has smooth, double flanges that mate both to the cover and the mounting enclosure to provide flame tight joints. The screws consist of stainless steel hex head screws and attach the cover to the mounting enclosure. The side rocker arm push button has lockout holes, and the switches are supplied with an internal ground screw. The EPS-2XPB-SG-M2 housing is made out of a malleable aluminum body with a cast copper free aluminum alloy cover, and is epoxy powder coated for a natural finish. This switch is rated for Class I, Divisions 1 & 2 Groups C & D, Class I, Zones 1 & 2 Groups IIA, Class II, Divisions 1 & 2 Groups E, F & G and Class III. Hubs: This push button switch is offered in a feed-through or dead-end configuration and a choice of 1/2" NPT or 3/4" NPT hub size.
