16A Explosion Proof Manual Starter Switch - Class I, II, III - 600V Rated - Thermal Overload Protect

LARSON ELECTRONICSSKU: PL3-EPS-TPS-16A
filler

Precio:
Precio de venta$1,332.00

Descripción

Specifications / Additional Information
' Product Overview '
The EPS-TPS-16A from Larson Electronics is an Explosion Proof Manual Starter Switch that is suitable for Class I, II and III flammable environments. Equipped Class 10 thermal overload protection, this 16-amp unit is rated at 600V AC. The explosion proof switch is constructed of malleable Aluminum and is offered in feed-through or dead-end configurations, with 1/2" NPT or 3/4" NPT hubs. The EPS-TPS-16A is an explosion proof switch designed for applications in combustible work environments. Capable of handling loads up to 16 amps, this 2-pole unit is rated at 600V AC. Thermal overload protection is provided by a Class 10 Ambient-Compensated Thermal Overload Relay. This feature enables temporary overload at startup, with a Class 10 rating providing up to 10 seconds of overload condition before tripping the circuit. Ambient compensation reduces the possibility of false tripping, by taking the ambient temperature into consideration.
Click Photo to Enlarge
The EPS-TPS-16A explosion proof switch cover and housing box is constructed of malleable aluminum with all arcing devices contained within an explosion proof labyrinth switch for the highest protection possible. The entire unit is triple coated with zinc electroplate, chromate, and a final epoxy powder coat for maximum durability and corrosion resistance. A bushing seal at each conductor opening prevents damage to wiring insulation and a triple coat housing finish provides rugged protection against corrosion. Hubs: This explosion proof unit is offered with 1/2" NPT or 3/4" NPT hubs. NPT tapped conduit openings are provided on the top and bottom of the unit in feed through versions, while dead end versions have a single conduit hub, providing easy and secure connection to main power line supplies. Each hub opening is fitted with an integral bushing to prevent fraying or damage to insulation. Mounting: Two external mounting lugs provide simple and secure mounting of the unit to walls and flat surfaces. The unit box, switch and face plate are all included with the product. Suggested Applications: Manufacturing, Industrial, Warehouse, Lighting, Lighting, Wet areas or Locations Where Combustible Dust is Present.
Specifications / Additional Information
EPS-TPS-16A Explosion Proof Manual Switch Ratings
Listing: United States, Canada Class I, Division 1&2 Groups C,D
Unit Dimensions: 3.00"-W X 4.69"-D X 6.13 "-L Class II, Division 1&2 Groups E,F,G
Weight: - Class III
Voltage Rating: 600V AC, 1PH NEMA 7 (C,D) 9 (E,F,G)
Amps: 16A
Poles: 2P
HP: 1HP @ 230V AC, 1HP @ 120V AC; 3/4 HP @ 115V DC, 3/4 HP @ 230V DC
Operation: Toggle
Protection: Class 10 Ambient-Compensated Thermal Overload Relay
Insulation: Integral Bushings in Conductor Openings
Unit Materials: Box/Receptacle- Malleable Aluminum, Sealing Chamber-Aluminum
Finish: Triple-coat€”Zinc Electroplate, Chromate, Epoxy Powder Coat
Mounting: External Mounting Lugs on Body
Grounding: Single Internal Housing Ground Screw
Configuration: Feed Through or Dead End
Hub Size Options: 1/2" NPT or 3/4" NPT
