7.5kVA Explosion Proof Transformer - C1D1 - 1PH - 240/480V Primary - 120/240V Secondary

LARSON ELECTRONICSSKU: PL3-ETX-480.1P-7.5KVA-120
filler

Precio:
Precio de venta$13,126.00

Descripción

Specifications / Additional Information
ETX-480.1P-7.5KVA-120 Explosion Proof Transformer Ratings/Approvals
Unit Type: Explosion Proof Transformer Class I, Division 1 & 2, Groups C & D
Dimensions: 28.38" x 28.38" x 14.187" Class II, Division 1 & 2, Groups E, F, G
Phase: Single Phase UL Listed
kVA: 7.5 NEMA 4X
Primary Voltage: 240/480V AC
Secondary Voltage: 120/240V
Frequency: 60Hz
Primary/Secondary Configuration: Two Winding
Winding Material: Copper
Termination: Leadwires
Electrostatically Shielded: Yes
Temp Rise/Insulation: 115°C/180°C
Sound Level: Meets NEMA ST-20 Standards
Enclosure Material: Cast Aluminum
Input/Output Hubs: 3/4" NPT Input and 3/4" NPT Output Hubs
Mounting: Surface
Weight: 200 lbs

' Product Overview '
The ETX-480.1P-7.5KVA-120 by Larson Electronics is an explosion proof transformer for use in hazardous locations. Suitable for both indoor and outdoor applications, the ETX-480.1P-7.5KVA-120 provides increased reliablity, protection against critical equipment failures and an extra level of protection by isolating the power source from the connected device. *PLEASE NOTE: ANY FREE SHIPPING OFFERS DO NOT APPLY TO POWER DISTRIBUTION PANELS, TRANSFORMERS, OR SUBSTATIONS* Transformer Features: With a transformer rating of 7.5kVA, the ETX-480.1P-7.5KVA-120 is a single phase unit with a primary voltage of 240/280V AC. It also provides a secondary voltage of 120/240V. The transformer contains a two-winding primary and secondary configuration and reverse connectables, as well as electrostatically shielded components and wire leads connection. Featuring robust construction, the enclosure is made out of cast aluminum. The explosion proof transformer comes with a NEMA 4X rating, which offers watertight protection and corrosion resistance. The following input/output hubs can be found on this unit: 3/4" NPT (input) and 3/4" NPT (output). The ETX-480.1P-7.5KVA-120 may be mounted on compatible surfaces in Class I and Class II environments. This transformer provides owners with significant energy savings as well as offering environmental benefits. Higher efficiency not only extends the life of the transformer, but also turn into cost savings for owners in the form of lower energy bills and decreased cost of ownership. Applications: Chemical processing plants, oil refineries, wastewater facilities and other classified industrial facilities that adheres to the ratings of this unit. Larson Electronics is a manufacturer and as such can build stationary and portable transformer systems to your specifications. Although we carry several models of power distribution transformer systems, we can deliver custom ordered units almost as quickly as our prebuilt units. If this model does not meet your needs, please contact us at 1-800-369-6671 or to discuss your specific requirements.
