24W Explosion Proof POE Injector - Adds Power Over Ethernet Functionality to Cameras - 48V - 0.5 Amp - NO Cord Cap
24W Explosion Proof POE Injector - Adds Power Over Ethernet Functionality to Cameras - 48V - 0.5 Amp - NO Cord Cap
| EXP-IP-POE-INJ-48V-24W-JB Explosion Proof POE Injector | Ratings/Approvals |
| Device Type: Explosion Proof POE Injector | NRTL Listed for United States, Canada, Europe, Asia |
| External Dimensions: 4-17/32"H x 6-1/8"W | Class I, Div. 1 & 2, Groups A, B, C, D |
| Weight: 4 lb | Class I, Zones 1 & 2, Groups IIB+H2, IIA |
| Input Voltage: 120 V or 240 V AC | Class II, Div. 1 & 2, Groups E, F ,G |
| Watts: 24W | Class III, Div. 1 & 2 |
| Output Voltage: 48 V DC | NEMA Type 3, 4, 4X, 7 (B,C,D), 9 (E,F,G) |
| Max Amp Rating: 0.5 | ATEX Ex II 2 G / D |
| Power Efficiency: >90% | IECEx db IIC Gb |
| Ambient Temperature Range: -20°C to +50°C | IECEx tb IIC Db IP66 |
| Cover Material: Copper-free Aluminum Alloy | |
| Allen Head Cover Screw Material: Cadmium Plated Steel | |
| Sealing Gasket: Neoprene O-ring | Special Orders - Requirements |
| Ground Screw Material: Zinc Plated Steel w/ Green Dye | |
| Enclosure Finish: Silver Powder Epoxy Paint, Electrostatically Applied | Toll Free: 1-800-369-6671 |
| Design: Single Cover Box Only | Intl: 1-214-616-6180 |
| Wiring Hubs: Offset Feed-thru (3/4" NPT) | |
| Wiring: Operators Complete Connections via Rigid Conduit or Cord |
| The EXP-IP-POE-INJ-48V-24W-JB from Larson Electronics is an Explosion Proof POE Injector that allows operators to add POE (Power over Ethernet) functionality to explosion proof cameras and sensors. POE functionality adds flexibility, safety, reliability and scalability to camera systems as well as saving both time and money. The EXP-IP-POE-INJ-48V-24W-JB is a 24V POE Injector that is rated for devices that draw up to 1 amp. This POE injector features an explosion proof enclosure that is Class I, Divisions 1 & 2, Groups A, B, C, D, Class I, Zones 1 & 2, Groups IIB+H2, IIA, Class II, Divisions 1 & 2, Groups E, F ,G and Class III Divisions 1 & 2 rated for hazardous areas and is listed for use worldwide including the United States, Canada, Europe and Asia. The EXP-IP-POE-INJ-48V-24W-JB reduces the amount of cables that must be run to cameras. It achieves this by running the power required by the device through the Ethernet cable instead of a separate power cable. This saves operators both time and money. Not only because of reduced cable costs, but also because network cables do not require a professional electrician to install like some power cables do. POE also makes it simple to move cameras to the desired or required location with much less hassle than more traditional systems. Adding additional cameras also becomes a simple task with a POE system. Operators simply run Ethernet cable into one side of the EXP-IP-POE-INJ-48V-24W-JB and back out the other. The POE injector allows operators to make connections via rigid conduit or by running cord to the unit. |
