Explosion Proof Ethernet Switch - Class I, II, III - 4 Ports - 802.3af Compliant - (4) 1/2" NPT Hubs

LARSON ELECTRONICSSKU: PL3-EXP-IP-POE-NW-SW-5P-4XPOE-R1-2X0.5N-2X0.5S
filler

Precio:
Precio de venta$5,916.00

Descripción

Specifications / Additional Information
EXP-IP-POE-NW-SW-5P-4XPOE-R1-2X0.5N-2X0.5S Explosion Proof Ethernet Switch Features/Ratings
Listing: NRTL Listed for United States, Canada Class I, Divisions 1 & 2, Groups B**, C, D
Dimensions: 12.32'' (312.93mm) L x 12.32'' (312.93mm) H x 8.09'' (205.49mm) D Class I, Zones 1 & 2, Groups IIB+H2, IIA
Weight: - Class II, Divisions 1 & 2, Groups E, F, G
Voltage: - Class III, Divisions 1 & 2
Number of Ports: 4 NEMA 3R, 4, 7, 9
Wattage (Per Port): 15.4W (56W Total) NRTL Certified to UL 886
Power Over Ethernet: 802.3af NRTL Certified to UL 698
Design: Fanless NRTL Certified to UL 1203
Operating Window: N/A NRTL Certified to CSA C22.2 No 30
Ambient Operating Temp Range: - 802.3af Compliant
Operating Temp Rating: - **Conduit seals required within 18" for Group B applications
Enclosure Material: Copper Free Cast Aluminum (less than 4/10 of 1%)
Hardware Material: Zinc Plated Steel
Enclosure Finish: Aluminum Lacquer Paint; Custom Available
Mounting: Surface Mount Legs
Mounting Leg Height: 0.25"
Mounting Dimensions Height: 4.00'' (101.60mm) Center to Center
Mounting Dimensions Width: 9.88'' (250.95mm) Center to Center
Hubs: (4) 1/2" NPT - (2) North Side, (2) South Side
' Product Overview '
The EXP-IP-POE-NW-SW-5P-4XPOE-R1-2X0.5N-2X0.5S from Larson Electronics is an Explosion Proof Ethernet Switch that is designed for applications in Class I, II and III rated combustible facilities. Equipped with four ports and a fanless design, this explosion proof unit is ideal for indoor or outdoor applications where flammable vapors, gases, or dusts exist or stand the potential to exist. Operators may access four, 1/2" NPT hubs on the device. The EXP-IP-POE-NW-SW-5P-4XPOE-R1-2X0.5N-2X0.5S explosion proof 4-port POE network switch provides power to cameras when they are not wired directly to the NVR. Designed for combustible sites, this network switch offers four 802.3af ports that each provide up to 15.4W per port for a total of 56W. The device has a fanless design for quiet operation, and simple plug and play setup. During installation, it is recommended for line-in power and line-in ethernet to be ran through different conduits. This explosion proof unit is constructed of cast aluminum, equipped with steel bolts and includes a weatherproof gasket for a NEMA 3R / NEMA 4 protection rating. This hazardous location device is NEMA 7 (Groups B, C, and D) and NEMA 9 (Groups E, F, and G) rated. The enclosure features four, 1/2" NPT conduit hubs for completing wiring connections (two hubs on the north side and two hubs on the south side). Customized conduit taps can be factory drilled using Larson Electronics CNC machines at an additional cost. The lid of the enclosure allows for a maximum of 9 long operator devices (switches, push buttons, indicator lights, etc.) in a configuration of 3 rows of 3. Customized boxes with selected operators can be factory installed at customer's request.
Click Photos to Enlarge
Click To Enlarge Click To Enlarge
Larson Electronics can customize each unit with drilled and tapped operator hubs and/or conduit hubs per customer request. Please view the above and below images for orientation. When looking at the top cover (labeled Lid), all four sides are labeled for the orientation when looking at the Lid. All hubs are CNC machined for precision. Please see below specifications table for included taps and dimensional drawing for exact locations.
Click To Enlarge Click To Enlarge
Construction: These explosion proof ethernet switches are NEMA 3R rated, for indoor and outdoor use and provide a degree of protection against dirt, water, and ice. NEMA 4X equipment can be equipped upon request. NEMA 4X models include all stainless steel external hardware. Operator lid hinges can be fitted on the enclosure for regular opening and closing. Breather plugs, drain plugs, and grounding lugs can be added at customer request. Customization: Larson Electronics can customize this unit for compatibility with existing systems, assemblies, work flows and processes or assist in designing units for new installation. We can add indicator lights, windows, hinges, operator handles, push button switches, momentary push button switches, emergency stop push buttons, selector switches, on/off switches, terminal blocks, relays, PLCs, mounting pans and more. Customized labels are also available for each operator in order to meet various requirements. Conduit openings can be tapped on all sides and back of the explosion proof enclosure, at an additional cost. Tapping of conduit hubs is facilitated at Larson Electronics using a CNC machine for precise cutting. Larson Electronics offers customization on conduit opening size and locations. Taps include female NPT (National Pipe Thread), female BSPT (British Standard Pipe Thread), and Metric ISO thread. Please contact us for specific requirements. Additional equipment can be provided from factory, including nipples, unions, seal-offs, and operator devices. Suggested Applications: The explosion proof unit approved for use within indoor and outdoor environments where flammable or combustible gases, vapors, dusts, fibers, and flying exist or stand the potential to exist, and is ideal for a wide variety of applications. Applications include but not limited to aircraft maintenance, alcohol processing, aerospace, chemical manufacturing, coke processing, cold storage, compressed natural gas (CNG) facilities, cranes, cryogenics, distilleries, food processing, fuel storage, gas processing plants, grain processing, laboratories, liquefied natural gas (LNG) facilities, liquid propane gas (LPG), machine operations, manufacturing, marine vessels, methane production, mining, offshore, oil drilling rigs, oil refineries, paint spray booths, paper processing, petrochemical, petroleum refineries, pharmaceuticals, power plants, production refineries, sand blast cabinets, sewage and septic tanks, shipyards, solvent and cleaning areas, storage facilities, tank farms, tankers, textile, washdown areas, waste treatment plants, and woodworking. .
