Explosion Proof Timer - Class I, II, III Div 1 & 2 - ATEX/IECEX - Accessory for EXP-MS-30W-N4X
Explosion Proof Timer - Class I, II, III Div 1 & 2 - ATEX/IECEX - Accessory for EXP-MS-30W-N4X
| J13816 Explosion Proof Timer | Ratings/Approvals |
| Device Type: Explosion Proof Timer | Listed for United States, Canada, Europe, Asia |
| Dimensions: 6.63" x 5.5" x 5.25" | Class I, Div. 1 & 2, Groups B, C, D |
| Weight: - | Class I, Zones 1 & 2, Groups IIB+H2, IIA |
| Range: 9 Seconds to 120 Minutes | Class II, Div. 1 & 2, Groups E, F, G |
| Lens Opening: 3" | Class III, Div. 1 & 2 |
| Material: Copper-free Aluminum | NEMA Type 3, 4, 4X, 7 (B,C,D), 9 (E,F,G) |
| Enclosure Finish: Electrostatically Applied Powder Epoxy/Polyester Finish | ATEX/IEC Ex |
| Lens Material: Tempered Soda Lime Glass | Ex d IIC T6 or T5 |
| Mounting: Surface | Ex tD A21 IP66 T80°C or T90°C IP66 |
| Maximum Conduit Size: 2" | Ta = -20°C to +60°C |
| Wiring Hubs: (2) 1/2" or 3/4" NPT hubs, (1) North and (1) South | |
| Â | |
| Â | |
| Â | Toll Free:Â 1-800-369-6671 |
| Â | |
| Â | |
| Â |
| The J13816 from Larson Electronics is an Explosion Proof Timer for flammable work sites. This unit enables operators to apply timed settings for the Larson Electronics EXP-MS-30W-N4X explosion proof motion sensor. The timer is constructed of copper-free aluminum and is protected by a NEMA rated enclosure. The J13816 provides timed settings for the Larson Electronics EXP-MS-30W-N4X explosion proof motion sensor and other compatible equipment. This unit offers a range of 9 seconds to 120 minutes. During use, a relay holds the circuit open for 60-120 minutes. Upon detecting motion in the area, the timer is activated/set for 60-120 minutes. If the connected explosion proof motion sensor (EXP-MS-30W-N4X) is unable to detection motion during the duration of the timed setting, the device deactivates/turns off all connected lights in the facility. Constructed of copper-free aluminum, the ATEX/IECEX-rated timer is protected by a tempered soda lime glass lens. The explosion proof timer is rated NEMA Type 3, 4, 4X, 7 (B,C,D) and 9 (E,F,G) and designed to withstand the rigors of demanding environmental and operating conditions while remaining robust and easy to use. This unit is compatible with conduit sizes up to 2". Cast mounting lugs are available for mounting. Applications: Accessory timer for EXP-MS-30W-N4X. |
