Explosion Proof Soft Starter - Class I, II, III - 5 HP, 7.5 Amps - 480V - 3PH Delta, 3-Wire - 50/60 Hz
Explosion Proof Soft Starter - Class I, II, III - 5 HP, 7.5 Amps - 480V - 3PH Delta, 3-Wire - 50/60 Hz
| EXP-MTSTR-SF-3P-480V-5HP-7.5A-DCM-4X0.75S Explosion Proof Soft Starter | Ratings |
| Listing: NRTL Listed for United States and Canada | Listed for NEC, CEC, ATEX, and IEC Ex |
| Unit Type: Explosion Proof Reduced Voltage Starter | Class I, Divisions 1 & 2, Groups B, C, D |
| Dimensions: 10.62"L x 5.74"W x 6.29"H | Class I, Zones 1 & 2, Groups IIB+H2, IIA |
| Weight: - | Class II, Divisions 1 & 2, Groups E, F, G |
| Capacity: 5 HP | Class III, Divisions 1 & 2 |
| Power: 3.75 kW | NEMA 3R, 4, 7, 9 |
| Voltage: 480V | NRTL Certified to UL 886 |
| Phase: 3PH Delta, 3-Wire Configuration | NRTL Certified to UL 698 |
| Frequency: 50/60 Hz | NRTL Certified to UL 1203 |
| Amps: 7.5A (Secondary) | NRTL Certified to CSA C22.2 No 3 |
| Starting Times: 20x per hour (Maximum) | Ex d IIB + H2 T5 or T6 |
| Adaptive Motor: Squirrel-cage 3PH Asynchronous | Ex tD A21 IP66 Tamb ≤ + 60°C |
| Control Modes: Operation Panel Control, Operation Panel + External Control, External Control, External Control + COM Control, Operation Panel + External + COM Control, Operation Panel + COM Control, COM Control, No Start or Stop Operation | NRTL Certified to IEC 60079 |
| Start Modes: Current-limiting to Start, Voltage Ramp to Start, Torque Control + Current-limiting to Start, Torque Control + Voltage Ramp to Start, Current Ramp to Start, Voltage Current-limiting Double Closed-loop Start | NRTL Certified to EN 60079 |
| Stop Modes: Soft Stop, Free Stop |  |
| Vibration: <0.5G |  |
| Operating Temp: -30°C - +55°C |  |
| Humidity: 90% RH w/o Dew Condensation |  |
| Altitude: Below 3,280.84 Feet |  |
| Enclosure Material: Copper Free Cast Aluminum (less than 4/10 of 1%) | Special Orders - Requirements |
| Hardware Material: Zinc Plated Steel | |
| Enclosure Finish: Aluminum Lacquer Paint; Custom Available | |
| Mounting: Surface Mount Legs | |
| Mount Leg Height: 0.25" | |
| Hubs: (4) 3/4" NPT |
Made in the USA
The Larson Electronics EXP-MTSTR-SF-3P-480V-5HP-7.5A-DCM-4X0.75S Explosion Proof Soft Starter provides reduced voltage starting solutions for industrial equipment in Class I, III and III rated environments. This 5 HP unit offers compatibility with 480V three-phase delta, 50/60 Hz. Multiple start, stop and control modes are available during use. Operators can mount the unit on surfaces, via four mounting legs at the back of the enclosure.
The EXP-MTSTR-SF-3P-480V-5HP-7.5A-DCM-4X0.75S is an explosion proof reduced voltage starter, which can be used to soft start and preserve industrial motors inside combustible sites. This 5 HP unit is compatible with 480V three-phase delta, 50/60 Hz. The 7.5-amp soft starter is equipped with a squirrel-cage three-phase asynchronous motor. Starting times should not exceed 20 attempts per hour.
This reduced voltage starter is protected by a copper-free aluminum enclosure with an aluminum lacquer paint finish. A weatherproof gasket enable the NEMA 3R/4 rated device to be used in both indoor and outdoor hazardous locations. The presence of corrosive gas or conductive heat may hinder the performance of the soft starter. The EXP-MTSTR-SF-3P-480V-5HP-7.5A-DCM-4X0.75S is designed for use at altitudes below 3,280.84 feet (1,000 meters). Above this range, the rate of power must be increased during operation.
The explosion proof soft starter features the following operating modes and protective functionalities:
|
