1HP Explosion Proof Variable Frequency Device - 100-120V AC 1PH Input/Output - 16 Amps
1HP Explosion Proof Variable Frequency Device - 100-120V AC 1PH Input/Output - 16 Amps
| EXP-VFD-1P-110.120-1HP-16A-DCM Explosion Proof Variable Frequency Device | Features/Ratings |
| Unit Type: 1 Phase Input / 1 Phase Output Variable Frequency Device | Class I, Divisions 1 & 2 |
| Dimensions: 16.38" x 22.38" x 9.06" | Class II, Divisions 1 & 2 |
| Weight: - | Automatic Voltage Regulation |
| Input/Output Voltage: 100-120 V AC, 1PH | PLC Multi-step Speed Control |
| Kilowatts: 0.75 kW |  |
| Output Current: 16 Amps |  |
| Input Frequency: 48 to 63 Hz |  |
| Output Frequency: 0 to 400 Hz | Special Orders - Requirements |
| HP: 4 | |
| Motor Control: IC+IGBT | Toll Free: 1-800-369-6671 |
| Materials: Copper-free Aluminum | |
| Mounting: Surface | |
| Color: Gray |
| The EXP-VFD-1P-110.120-1HP-16A-DCM from Larson Electronics is an Explosion Proof Single-Phase Input, Single-Phase Output Variable Frequency Drive that is suitable for improving AC motor performance in industrial operations. This unit features single-phase 100-120 V AC input/output voltage. The 1 HP device supports PLC multi-step speed control. The EXP-VFD-1P-110.120-1HP-16A-DCM offers accurate AC motor control in hazardous locations and industrial facilities. This unit is compatible with single-phase 100-120 V AC input/output voltage. Input frequency range includes 48 to 63 Hz and output frequency ranges between 0 to 400 Hz. Designed for steady speed error, fast torque rise and protection from resonance vibrations, the 1 HP device provides an output current of 16 amps. This explosion proof VFD is protected by a copper-free aluminum housing. The unit is rated for use in Class I, Divisions 1 & 2 and Class II, Divisions 1 & 2 hazardous locations, making it ideal for indoor or outdoor applications where flammable vapors, gases or dust exist or stand the potential to exist. Mounting: Operators may mount the explosion proof VFD phase converter on compatible surfaces. Applications: Speed control of AC motors, industrial machines, large compressors, energy savings and more within Class I & II, Divisions 1 & 2 hazardous locations. |
