Flameproof Double Push Button - 250V AC/110V DC - Momentary - Lockout Green - ATEX/IECEx
Flameproof Double Push Button - 250V AC/110V DC - Momentary - Lockout Green - ATEX/IECEx
| HLSW-AE.EX-PMU-PB-16A-MS-2X.RG-C3-R-W1-G1 Flameproof Double Push Button | Ratings |
| Listing: NRTL Listed for ATEX/IECEx Locations | Approved for Zone 1 and 2 |
| Unit Type: Explosion Proof Double Push Button w/ Lockout | Approved for Zone 21 and 22 |
| Dimensions: 3.03" x 4.13" x 1.73" (77mm x 105mm x 44mm) | ATEX EX II 2 GD |
| Weight: - | IEC Ex d e IIC T6/T5 Gb |
| Rated Voltage: 250V AC or 110V DC | IEC Ex t IIIC T80°C Db/T90°C Db |
| Rated Frequency: - | Temp Rating -40ƒ‰¤Ta‰¤40ƒ/55ƒ |
| Amperage Rating: 16A (250V AC), 1A (110V DC) | NRTL Certified to IEC 60079 |
| Mechanical Life: 100,000+ Operations | NRTL Certified to EN 60079 |
| Push Button Type: Double Momentary, Non-illuminated | CE Certified |
| Push Button Colors: Red/Green | Conforms to CE 0575 |
| Contact Configuration: (1) NO, (1) NC | IP66 Weatherproof |
| Lockout Type: Lockable Metal Hinge Plate for Single Push Button - Padlock, (2) Keys | Â |
| Lockout Designation: Green Push Button Only | Â |
| Operating Temp: -40°C to +50°C | |
| Materials: Non-sparking | |
| Mounting: Panel | |
| Terminals: 2.5mm | |
| Cable Entry OD: 5.5mm-13mm | |
| Color: Black | |
| PLEASE NOTE: The HLSW-AE.EX series of explosion proof switches, operators, buttons, lights, and dials are certified to European Union (ATEX) and International (IEC Ex) standards and are approved for installing in these locations. This unit IS NOT certified to United States (NEC) or Canadian (CEC) standards for hazardous location. This unit DOES NOT carry UL or CSA ratings. Please contact Larson Electronics for NEC/CEC equvilant version of this product if you intend to install the product in United States, Canada, or any country that followed NEC or CEC electrical standards. | |
| The Larson Electronics HLSW-AE.EX-PMU-PB-16A-MS-2X.RG-C3-R-W1-G1 Explosion Proof Double Push Button with Lockout is a compact solution for controlling industrial machinery or equipment in flammable environments. This device is compatible with 250V AC/110V DC and contains NO and NC contacts. The IP66-rated double push button is protected by a non-sparking housing. PLEASE NOTE: The HLSW-AE.EX series of explosion proof switches, operators, buttons, lights, and dials are certified to European Union (ATEX) and International (IEC Ex) standards and are approved for installing in these locations. This unit IS NOT certified to United States (NEC) or Canadian (CEC) standards for hazardous location. This unit DOES NOT carry UL or CSA ratings. Please contact Larson Electronics for NEC/CEC equvilant version of this product if you intend to install the product in United States, Canada, or any country that followed NEC or CEC electrical standards. The HLSW-AE.EX-PMU-PB-16A-MS-2X.RG-C3-R-W1-G1 is designed for use in Zones 1/2 and Zones 21/22 rated combustible locations. This double-push button unit is rated for 250V AC at 16 amps and 110V DC at 1 amp. Featuring more than 100,000 operating cycles, the device operates with momentary action for both red and green push buttons (maintained action is available at an additional cost). This push button can be added to custom control station builds that contain pilot lights, other push buttons, emergency stop, selector switches, sensors and more. The weatherproof unit contains (1) normally open and (1) normally closed contacts. A sturdy lockout component for a single push button deters tampering. This component consists of a metal hinged plate, which covers the green push button, and a padlock (two keys included). With this lockout configuration, only operators holding keys can provide approval or start the connected device. The red push button is always exposed, allowing any individual in the facility to stop the connected machine (for example, during emergency situations or presence of abnormal conditions). This explosion proof push button is constructed of non-sparking materials. The IP66-rated device is suitable for ATEX/IECEx rated work sites with operating temperatures ranging between -40°C and +50°C. There are no labels or marking on this push button. We offer both custom labels (upon request) and the following selection of markings at an additional cost: On, Off, Start, Stop, I, O, Forward, Reverse and directional arrows. Wiring: This non-illuminated device is equipped with 2.5mm terminals for wiring connections. Maximum outer cable diameter range for the hub is 5.5mm to 13mm. Mounting: The HLSW-AE.EX-PMU-PB-16A-MS-2X.RG-C3-R-W1-G1 is compatible with panel mounting applications. Applications: Petroleum refineries, chemical and petrochemical plants, paint spray booths, food manufacturing buildings, agricultural operations, grain storage centers, industrial equipment and more. |
| Â |
