Industrial Master Control Box - 120V - PLR w/ (10) Inputs - (2) 1/2" NPT Hubs
Industrial Master Control Box - 120V - PLR w/ (10) Inputs - (2) 1/2" NPT Hubs
IND-SW-CTR-120V-10X-SG-R1 Industrial Master Control Box | Ratings/Approvals |
Unit Type: Master Control Box | NEMA 3R |
Internal Dimensions: 8" x 8" x 4" | Weatherproof |
Weight: - | Corrosion Resistant |
Input Voltage: 120V AC | Â |
Inputs: (10) Inputs | Â |
Current Rating: 8A | Â |
HP Rating: 1/3HP @ 120V | Â |
Maximum Load: Resistive- 8A/point; Inductive- 4A/point | Â |
Maximum Operating Time: 15ms (Normal Condition) | Â |
Minimum Load: 16.7mA | Â |
Programming Languages: Ladder/Function Block | Â |
Program Memory: 300 Lines or 260 Function Blocks | Â |
Programming Storage Media: Flash | Â |
Execution Speed: 10ms/cycle | Â |
LCD Display: 4 Lines x 16 Characters | Â |
Function Keys: 8, 4 User-defined (Z Inputs) | Â |
Auxiliary Coils: 126 (63 M-coils, 63 N-coils) | Â |
Timers: 31 T-coils | Â |
Timing Ranges: 0.01s€“9999min |  |
Counters: 31 C-coils | Â |
RTC (Real Time Clock): 31 R-coils | Â |
Resolution: 1 Min | Â |
Time Span Available: Week, Year, Month, Day, Hour, Min | Â |
Daylight Savings Feature: Yes | Â |
Power Off RTC Retention: 240 Hours | Â |
Compare Instructions (Analog, Timer, or Counter Values): 31 G-coils | Â |
Compare Functions: EQ, LT, GT, LE, GE, NE | Â |
PID Control (Proportional-Integral-Derivative): 15 Loops (PI Coils) | Â |
Math Instructions: 62 (31 AS Coils, 31 MD Coils) Up to 124 Additional (Plus Unused T, C, R, G coils) | Â |
Math Operations: + - x / | Â |
Data Multiplexer Instructions: 15 (MX Coils) | Â |
Resolution: 2-bit, 4 Data Registers | Â |
Data Registers: 240 (DR Coils, 16-bit) | Â |
Shift Instruction: 1 8-bit (S Coil) | Â |
Analog Ramp Instructions: 31 (AR Coils) | Â |
Current Consumption: 3.2mA @ 24V DC | Â |
Transistor Type: 3-wire PNP Sensor Compatible | Â |
High Speed Input Frequency: 1kHz | Â |
Standard Input Frequency: < 40 Hz | Â |
Required Protection: Inverse Voltage Protection | Â |
Resolution: 12 bit | Â |
Protection: Short Circuit | Â |
Life Expectancy (Rated Load): 100k Operations | Â |
Operating Temperature Range: -20° to 55°C | |
Housing Materials: Plastic Molding Compound and Polycarbonate | |
Contact Material: Ag Alloy | |
Mounting: Surface via (4) Openings | |
Wire Size: 26 to 14 AWG | |
Hub Qty/Size: (2) 1/2" NPT Hubs @ South Side |
The Larson Electronics IND-SW-CTR-120V-10X-SG-R1 Industrial Master Control Box is ideal for controlling an output device via multiple inputs in rugged work sites. This NEMA 3R rated unit operates on 120V and features a total of 10 inputs. The weatherproof device features two 1/2" NPT hubs at the south side of the unit for wiring connections. The IND-SW-CTR-120V-10X-SG-R1 facilitates multiple wiring connections for controlling devices and equipment in industrial sites. Equipped with a programmable logic relay, the unit has a total of 10 inputs and is capable of controlling one device on the output side. This industrial box is constructed of plastic molding compound and polycarbonate. Ideal for both indoor and outdoor use, as well as marine locations, the NEMA 3R rated device offers superior corrosion resistance. Hubs: The IND-SW-CTR-120V-10X-SG-R1 has two 1/2" NPT hubs on the south side of the enclosure. Mounting: Operators may mount the weatherproof unit on surfaces via four mounting holes at every corner. Applications: Industrial buildings, marine locations, motor control, wood shops, fans, lights and more. |
 |
