3 Watt Infrared LED Light - Board and Driver Only - 9-42V DC - 750nm, 850nm or 940nm

LARSON ELECTRONICSSKU: PL3-LEDLB-1-IR-256
filler

Precio:
Precio de venta$322.00

Descripción

Specifications / Additional Information
LEDLB-1-IR-256 Infrared LED Light Board/Driver LEDLB-1-IR Features
Lamp Type: Infrared LED Low Amp Draw
Watts: 3 Small Size
Led Drive %: 80% 50,000 Hour Service Life
Voltage: 9-42 VDC Shock Vibration Resistant
Mounting: User provided  Ambient Op Temp -45C to 85C
Wiring: N/A CE Certified
Amps: 0.25 (on 12 volts) 0.13 (on 24 volts)
LED Light Color: Infrared 750nm, 850nm or 940nm
LED Life Expectancy: 50,000 hours
No warranty

' Product Overview '
Buy American Compliant The LEDLB-1-IR-256 LED is an infrared LED light emitter that projects an infrared beam in the 750NM, 850NM, or 940NM wavelengths. This IR LED board includes a high powered 3 watt LED emitter and LED driver. This infrared light produces a beam that can only be seen through the use of night vision goggles or equipment. The value in this IR LED fixture is in the power and form factor. This LED assembly draws only a 1/4 amp on 12 volts. A small profile, low power requirements, and high durability of LED technology makes these LED lights ideal for commercial use as well as a wide array of applications including but not limited to: military, industrial manufacturing, machine visioning and non destructive testing, security and law enforcement, and boating.
Heat Management: Heat is the single largest factor in premature LED failure and color shifting. As a result, many manufacturers reduce the output of their LEDs to reduce the amount of heat produced. Operators must supply their own heat sink to allow proper cooling of this infrared LED assembly. Voltage Control: These units are able to adjust input current to maintain the correct LED voltage levels regardless of input levels across a specific range. These LEDLB series LED lights can operate on current ranging from 9 to 42VDC without any modifications necessary as a result. This multi-voltage capability makes these units ideal for mobile and standalone applications such as those found on commercial boats, heavy equipment and vehicles where power systems don’t always operate with 12 volts and external generators, transformers or inverters are impractical. Options: These particular units are available in 750, 850 and 940nM wavelengths. 850nM is typically useful with older versions of night vision and commercially available security cameras and devices with night vision capability. These units are also available in spot or flood configurations to allow a tighter beam for longer range or a wider beam for illumination of larger areas closer to the fixture. Choose options below when ordering.
