1 kVA Hazardous Location Transformer - Single Phase - 480V Primary - 120V Secondary - NEMA 3R

LARSON ELECTRONICSSKU: PL3-MT-HAL-1P-480V-1KVA-120V-N3R
filler

Precio:
Precio de venta$2,374.00

Descripción

Specifications / Additional Information
MT-HAL-1P-480V-1KVA-120V-N3R Hazardous Location Transformer Approvals/Ratings
Phase: Single Phase Listed for United States and Canada
Frequency: 60Hz ANC Cooling
kVA: 1 Class I Division 2, Groups A, B, C, D
Primary Voltage: 480V Class I Zone 2 Group IIC
Secondary Voltage: 120V NEMA 3R Enclosure
Winding Material: Aluminum T3C Approval
Insulation: 130°C
Temperature Rise: 80°C
Impedance: 1 - 5%
Primary Termination (Std): Lead Wires
Secondary Termination (Std): Lead Wires
Sound Level: Meets NEMA ST-20 Standards
Enclosure Material: NEMA Type 3R Heavy Duty Ventilated
Finish: ANSI 61 Grey, UL50 Finish
Dimensions: 14.25"-H x 9.75"-W x 9"-D
Weight: 35 lbs
' Product Overview '
The MT-HAL-1P-480V-1KVA-120V-N3R 480V 1 Phase Energy Efficient Hazardous Location Transformer from Larson Electronics is powerful, reliable and designed with the environment in mind. Suitable for both indoor and outdoor applications, the MT-HAL-1P-480V-1KVA-120V-N3R provides increased reliability and protection against critical equipment failures. The lower operating costs, lower heat emissions and lower cost of ownership make this transformer ideal for a wide range of applications and businesses. The MT-HAL-1P-480V-1KVA-120V-N3R is rated for use in Class I Division 2, Groups A, B, C, D and Class I Zone 1 Group IIC hazardous locations. *PLEASE NOTE: ANY FREE SHIPPING OFFERS DO NOT APPLY TO POWER DISTRIBUTION PANELS, TRANSFORMERS, OR SUBSTATIONS* Transformer Features: With a transformer rating of 1kVA, the MT-HAL-1P-480V-1KVA-120V-N3R hazardous location transformer is a single phase unit with a primary voltage of 480V. It also provides a secondary voltage of 120V. Featuring robust construction, this unit`s cores are manufactured with non-aging, cold-rolled silicon steel laminations using state of the art technology. This unit boasts a low cost of ownership and is highly energy efficient. Lower heat emissions mean less cooling is needed as well. The Standard Type 3R enclosure makes the unit suitable for both indoor and outdoor applications and it can be wall mounted. The unit also features 130°C insulation with an 80°C temperature rise. Benefits: The MT-HAL-1P-480V-1KVA-120V-N3R general purpose transformer offers many benefits to the consumer. Precision cut aluminum transformer winding material help to improve performance. The close tolerances used during manufacturing also eliminates burrs which hinder performance. Each core is specially coated to prevent the ingress of moisture and are electrically balanced to minimize axial forces during short circuit situations. This transformer provides owners with significant energy savings as well as offering environmental benefits. Higher efficiency not only extends the life of the transformer, but also turn into cost savings for owners in the form of lower energy bills and decreased cost of ownership. Integrated floor and wall mounting brackets make installation fast and easy and the offset outward facing floor installation holes allow for easy power tool access. Applications: General transformer purposes in C1D2 hazardous work areas. Larson Electronics is a manufacturer and as such can build stationary and portable transformer systems to your specifications. Although we carry several models of power distribution transformer systems, we can deliver custom ordered units almost as quickly as our prebuilt units. If this model does not meet your needs, please contact us at 1-800-369-6671 or to discuss your specific requirements.
