Mobile Rotary Phase Converter for 3HP Hard Loads - 208V 1PH to 3PH - 9 Amps Output, 7.5HP Idler - Cart Mount/N1

LARSON ELECTRONICSSKU: PL3-MTPC-PC-HD-RB-208V-7.5HP-3HP-N1-RCP
filler

Precio:
Precio de venta$6,746.00

Descripción

Specifications / Additional Information
MTPC-PC-HD-RB-208V-7.5HP-3HP-N1-RCP Rotary Phase Converter Ratings/Approvals
Unit Type: Portable Rotary Phase Converter Indoor Use (NEMA 1)
Phase Conversion: Single Phase to Three Phase Built-in Motor Starter
Kilowatt Rating: 5.6 KW Start/Stop Push Button Switch
Kilo Volt-Amp Rating: 7.5 KVA Accurate Voltage Balancing
Idle Motor Horse Power: 7.5 HP Power Indicator Light
Single Phase Voltage Input Plug: 30A L14-30P [125/250V] Made in the USA
Single Phase Voltage Input: 208V
Minimum Fuse/Circuit Breaker Size: 20
Maximum Fuse/Circuit Breaker Size: 40
Minimum Electrical Service Required: 10 KVA
Idle Amps: -
Service Load Type: Hard motor loads
Three Phase Voltage Output Connector: 30A L21-30C [120/208V]
Three Phase Voltage Output: 208V
Maximum Single Motor Load HP: 3 HP
Recommended Combined HP: 3 HP
Optimal Output Amps: 9A
Maximum Output Amps: 23.2A
Maximum Resistive Amps: 10A
Voltage Balance: 2-5%
Form Factor: Powder Coated Steel Dolly Cart
Color: Natural Gray
Weight: - lbs
Dimensions: -
Shipping Weight: - lbs
Shipping Dimensions: -
' Product Overview '
Made in the USA The Larson Electronics MTPC-PC-HD-RB-208V-7.5HP-3HP-N1-RCP 7.5 horsepower mobile rotary phase converter is designed to convert single phase power to three phase power for Hard motor loads. This phase converter accepts a single-phase 208V input and provides a three-phase 208V output. Operators may use this portable rotary phase converter to power equipment and machines with hard motor loads up to 3 horsepower and 9 amps that require three phase power in locations where only single phase power is available. Applications: The MTPC-PC-HD-RB-208V-7.5HP-3HP-N1-RCP is ideal for applications that utilize hard motor loads. This includes CNC laser table, CNC lathe, CNC mill, CNC plasma table, CNC router, CNC turning machine, CNC waterjet, cooling fan, exhaust fan, gearhead lathe, industrial fan, laser cutter, laser table, plasma cutter, plasma table, plastic grinder, printing press and any other application that induces a hard motor load up to a recommended 3 horsepower. The MTPC-PC-HD-RB-208V-7.5HP-3HP-N1-RCP rotary phase converter is suitable for converting single phase 208V on-site power to three phase 208V power for equipment. This 7.5 HP idler motor phase converter connects to existing 208V single phase via a 30-amp 125/250V L14-30P input plug. After conversion, the phase converter provides three-phase 208V on the output side at 9 continual amps with a maximum of 23.2 inrush amps. Operators may access a 30-amp 120/208V L21-30C connector for three-phase power on the output side. All MTPC series phase converters provide +/- 2-5% voltage balance on the output side, depending on the single phase input power, for maximum efficiency and reduced stress on the motor. This rotary phase converter features a built-in motor starter with a start/stop push button switch for seamless activation. Protective Construction: The MTPC-PC-HD-RB-208V-7.5HP-3HP-N1-RCP control panel is housed in a NEMA 1 enclosure, making it suitable for indoor environments. This level of protection allows the rotary phase converter to withstand the ingress of solid objects, such as falling dirt. The entire system is mounted on a powder coated steel, dolly cart style, frame resulting in an extremely stable, durable, and mobile power distribution platform. A dolly cart style mounting platform provides easier substation mobility, and a center point lift point allows easy lifting with cable or chain hooks. The MTPC series of rotary phase converters are designed to operate based on overall load size. This includes operating multiple devices from one rotary phase converter, providing the combined horsepower of all devices being operated simultaneously does not exceed the horsepower rating for the load type. This includes fractional motors up to 3 HP motors, and any combination of motor sizes in between. Instant reversal motors are no problem for the MTPC series phase converters. Each phase converter comes ready to install. Rotary Sizing: The MTPC-PC-HD-RB-208V-7.5HP-3HP-N1-RCP is sized for heavy/hard motor loads up to 3 horsepower. When correctly sized, Larson Electronics phase converters will provide years of trouble free service for your equipment. Larson Electronics offers single phase to three phase static and rotary phase converters for easy, medium, hard, and very hard motor loads. The motor load is dependent on the devices intended to operate on the phase converter. For additional load types or for additional sizes, please see the below links or call us today.
