Larson Remote Mount Solar Charge Control Kit - (8) Panels, (26) Li-ion Batteries, (2) Charge Controllers, (8) Mounting Kits - N3R Enclosure
Larson Remote Mount Solar Charge Control Kit - (8) Panels, (26) Li-ion Batteries, (2) Charge Controllers, (8) Mounting Kits - N3R Enclosure
The SCS-SPK-8X300PNL-SCS-1040AL-120.240-N3R-M1 is a solar-powered system that is designed to power up to 450 watts of equipment for up to 12 hours. This system includes eight 300-watt solar panels, eight surface mounting kits for the solar panels, twenty-six 40 aH lithium-ion batteries, two 60-amp charge controllers, NEMA 3R enclosure, 25-foot remote wiring kit and a 0.5 kVA solar inverter that provides 120/240 V output. The solar charge control kit provides one full day of automation without any sun to charge the batteries.
Solar Panels:
A total of eight, 300-watt solar panels are included with the system. The 300-watt, mono crystalline solar panels have a 60-cell orientation and carries a 15A maximum fuse rating. Each unit measures 64.9"L x 39.1"W x 1.38"H. Constructed of anodized aluminum (black), these solar panels are NRTL certified to UL 1703 and UL module fire performance: Type 2.
Connections for grounding are available at each corner of the units. Suitable for rugged conditions, the panels can withstand 25mm hail stones traveling at 51 mph.
The solar panel's proven junction box technology has 12 AWG PV wiring and works with transformerless inverters. Locking plug-in connectors offer operators safe and quick connections. Eighteen surface mount L-bracket kits are included, which can be used to mount the solar panels to the roof or flat surfaces.
Battery Bank/Charge Controller:
This system is equipped with twenty-six 40aH lithium-ion batteries, for a 1040 aH battery pack with 100% usable. Inside the enclosure, operators are provided access to two MPPT charge controllers. Capable of operating at 99% peak efficiency, each component features a maximum battery current of 60 amps. The 4-stage charge controllers can handle bulk, absorption, float and equalize charging stages. Protective features include the following: Overload, Short Circuit, High Voltage, High Temperature, Lightning/Transient Surges, Reverse Current @ Night. The controllers are supported by an included remote battery sensor. For connections to the controller, the following communication ports are available: MeterBus, RS-232, EIA-485, Ethernet, EMC-1
.
The batteries and MPPT charge controllers are housed inside a NEMA 3R rated enclosure, which can be mounted on floors. An included 25-foot remote wiring kit allows operators to mount the solar panels away from the charge controller during installation.
Applications:
Solar-powered systems, remote locations, alternative energy, sustainable energy systems, solar lighting, portable power, battery-powered systems, rechargeable lighting and more.
Contact info@purilite.ca for more information about our custom options tailored to meet your specific industry needs.
Specifications
Solar Panel Qty: (8)
Solar Cells: Monocrystalline 6 inches (156.75 x 156.75mm)
Panel Dimensions: 64.9"L x 39.1"W x 1.38"H
Cells Orientation: 60 Cells (6x10)
Ambient Operating Temperature: -40°C to +85°C
Maximum System Voltage: 1000V DC
Nominal Operating Cell Temperature (NOCT): 44°C
Temperature Coefficient of Pmax: - 0.40%/°C
Temperature Coefficient of Voc: - 0.31%/°C
Temperature Coefficient of Isc: 0.06%/°C
Peak Power Watts - PMAX (WP): 300W
Power Output Tolerance - PMAX (%): 0 ~ +5
Maximum Power Voltage - VMP (V): 32.2
Maximum Power Current - IMPP (A): 9.33
Open Circuit Voltage - VOC (V): 39.5
Short Circuit Current - ISC (A): 9.84
Fuse Rating: 15A
Module Materials: Anodized Aluminum, Black
Grounding: Grounding Points on Each Corner
Solar Inverter: 0.5 KVA 120/240V Output
Mounting: (8) Surface Mount L-bracket Kits for Mounting Solar Panels to Roof or Flat Surfaces
Dimensions: -
Battery Type: (26) 40aH Lithium-ion Batteries
Total Capacity: 1040aH
Total Usable: 1040aH - 100% Usable
Materials: Anodized Aluminum, Black Aluminum, Stainless Steel
Enclosure Type: NEMA 3R - Floor Mount
Charge Controller Qty: (2)
Voltage: 1000V DC 12 V, 24 V or 48 V DC 150V DC
Maximum Battery Current per Unit: 60A
Nominal Maximum Operating Power per Unit: 800W @ 12V, 1600W @ 24V, 3200W @ 48V
Peak Efficiency: 99%
Maximum PV Open Circuit Voltage: 150V DC
Battery Operating Voltage Range: 8-72V DC
Maximum Self-consumption: 2.7W
Transient Surge Protection: 4500W/Port
Charging Algorithm: 4-stage
Charging Stages: Bulk, Absorption, Float, Equalize
Ambient Operating Temp: –40°C to +45°C
Protection: 4500W/Port Overload, Short Circuit, High Voltage, High Temperature, Lightning/Transient Surges, Reverse Current @ Night, Remote Battery Sensor (RTS)
Communication Ports: MeterBus, RS-232, EIA-485, Ethernet, EMC-1
Wiring: 25' Remote Wiring Kit for Wiring Solar Panels Away from Charge Controller
