3 kVA Outdoor Rated Transformer - 120V Input to (1) 12V DC and (3) 24V DC Outputs - Weatherproof - 304 Stainless Steel Housing

LARSON ELECTRONICSSKU: PL3-TX-SS-120V-3KVA-10C-4XDC-3C-M1
filler

Precio:
Precio de venta$5,126.00

Descripción

Specifications / Additional Information
TX-SS-120V-3KVA-10C-4XDC-3C-M1 Power Transformer Ratings
Line-in Cord: 10' 16/3 SOOW Cord w/ Cord Cap
Line-in Cord Cap Options: 5-15 Straight or L5-15 Twist
Input Voltage: 120 V AC
KVA: 3 KVA
Output Voltage: 12 V DC and 24 V DC Special Orders - Requirements
Output Max Current: 30A Max per Output
Output Wiring: 3' 10/2 SOOW Cords with Blunt Cut Ends - (3) 24 V DC, (1) 12 V DC
Materials: 304 Stainless Steel
Dimensions: 10.00"H x 6.00"W x 6.00"D
Mounting: Surface Mount
' Product Overview '
Made in the USA The Larson Electronics TX-SS-120V-3KVA-10C-4XDC-3C-M1 3 KVA power transformer converts 120V AC to 12V and 24V DC. This unit is ideal for powering 12 and 24 volt based equipment and is equipped with a 304 stainless steel housing. This 3 KVA coil based power transformer accepts 120V AC electrical current and provides 12 volts and 24 volts on the output side. The transformer in this unit is encased within a weatherproof NEMA 3R rated enclosure and produces minimal interference with wireless radio receivers often found in remote controlled lighting equipment, such as Golight wireless remote controlled spotlights.
Click Photos to Enlarge
5-15 Straight Blade Plug 15 Amp / 125V Rated L5-15 Twist Lock Plug 15 Amp / 125V Rated
Wiring/Plug: The TX-SS-120V-3KVA-10C-4XDC-3C-M1 is equipped with 10 feet of 16/3 chemical and abrasion resistant SOOW cord that is fitted with an industrial grade cord cap for easy connection to common wall outlets. Plug options include standard 5-15 15 amp straight blade plug for 110V wall outlets with ground and NEMA L5-15 15 amp twist lock plug for 125V twist lock outlets. The output side contains three, 3' 10/2 SOOW cords with blunt cut ends for 24V DC outputs at 30 amps max per output. There is also one 10/2 SOOW cord with blunt cut end for 12V DC at 30 amps max connection. Mounting: This heavy duty stainless steel unit measures 10" tall x 6" wide x 6" deep, is surface mountable, and provides a reliable and low interference low voltage power solution for equipment requiring 12 V and 24 V DC.
