1/2HP VFD Phase Converter - 220-240V AC 1PH Input/3PH Output - 3 Amps - 0.4kW

LARSON ELECTRONICSSKU: PL3-VFD-1P-220.240-3P-0.5HP-3A-DCM
filler

Precio:
Precio de venta$1,290.00
 Más opciones de pago

Descripción

Specifications / Additional Information
VFD-1P-220.240-3P-0.5HP-3A-DCM Variable Frequency Device Features/Ratings
Unit Type: 1 Phase Input/3 Phase Output Delta, 3 Wire Variable Frequency Device Automatic Voltage Regulation
Dimensions: 5.59" x 3.34" x 4.44" LED Display
Weight: 4.4 lbs 1 Phase Input/3 Phase Output Delta, 3-Wire Configuration
Input/Output Voltage: 1 Phase 220-240V AC/3 Phase AC 0-Input Voltage Automatic Energy Save Running
Output Current: 3 Amps Automatic Current Limiting
Operating Frequency: 0 to 400 Hz
Kilowatts: 0.4kw
HP: 1/2
Speed Regulation: 1:100
Speed Control Accuracy: =±0.5% of rating synchronous speed
Frequency Resolution: Analog setting: 0.1% of max frequency; Digital setting: 0.01Hz
Frequency Precision: Digital setting: 0.01% max, Analog Setting: Max frequency X 0.2% max
Torque boost: Automatic torque boost; manual torque boost: 0.1%~30.0%
Communication Terminal: RS485 communication interface
Control Mode: V/F Control; Sensorless Vector Control
Overload Capacity: 150% @ 60s, 180% @ 3s
Operating Temp: –10°C to +40°C
Max Operating Humidity: 95% (non condensing)
Materials: -
Mounting: Surface
Color: Gray
' Product Overview '
The VFD-1P-220.240-3P-0.5HP-3A-DCM from Larson Electronics is a Single-Phase Input, 3 Phase Output, 3-Wire Configuration Variable Frequency Drive Phase Converter that is suitable for improving AC motor performance in industrial operations. This fan-cooled unit features a 220-240V AC input/output voltage comparability. Designed for steady speed error, fast torque rise and protection from resonance vibrations, the device provides an output current of 3 amps and an operating frequency range of 0 to 400 Hz with 1/2 horsepower. The VFD-1P-220.240-3P-0.5HP-3A-DCM offers accurate AC motor control in industrial facilities. This 0.4kw unit is compatible with single-phase input and three-phase output 220-240V AC voltage, provides an output current of 3 amps and an operating frequency range of 0 to 400 Hz. This device has a V/F control mode and sensorless vector control mode with an interior PID controlled, automatic energy save running to optimize the V/F curve, an automatic voltage regulator and automatic current limiting. The VFD-1P-220.240-3P-0.5HP-3A-DCM is designed for indoor applications and operating temperatures ranging between –10°C to +40°C. Operators may mount the VFD phase converter on compatible surfaces. This device measures 5.59" x 3.34" x 4.44" and weighs approximately 4.4 lbs. Applications: Speed control of AC motors, industrial machines, large compressors, energy savings and more.
