Larson 60 Watt Work Area LED Dock Light - 4' Switch Blade Dock Light - 5400 Lumens - 120-277V AC

PuriLite suggests you place an order directly with us for large Larson orders due to the potential customization requirements. Please call us at 1(647) 254-9757 to place your order. If you prefer to place your order online, a PuriLite agent will be in touch with you to discuss any custom options.
The Larson Electronics WAL-DL-WP60E-48-1227 Extendible Work Area Dock light provides operators with a powerful and energy efficient alternative to traditional gas burning filament luminaries. This LED swing arm is a direct replacement for 500 watt quarts halogen dock lights, and provides an pivoting 4` arm. LED technology and adjustable swing arm design makes this lamp an excellent replacement upgrade option for less durable and efficient halogen or HID loading bay and dock lights.
This work area LED dock light provides 5,400 lumens of high quality light while drawing only 0.5 amps at 60 watts on a 120V AC power source. The copper free aluminum alloy body of the LED light head is powder coated for added durability and an attractive aesthetic appearance. Special heat dissipating design in conjunction with LED technology helps this fixture to achieve an excellent 50,000 hour rated lifespan with 70% lumen retention. This light is constructed of three angled boards that helps provide a wider spread. Instead of the light only shining forward, the center board is concentrated to go straight out while the boards on the side are 45° offset. Six high output 10 watt LEDs, two per angled plane, producing 900 lumens each are paired with an angled reflector to produce a 120° flood beam spread to provide light over a larger area nearer the fixture.
The high output LED light head is mounted to an adjustable two-part swing arm constructed of light weight aluminum. The two piece arm design provides two pivot points, one at the mounting bracket and one in the center of the swing arm. The aluminum swing arm swings 170° from the mounting bracket point and 340° from the center pivot point, while the light head is vertically adjustable up to 270°, providing full adjustability for this 150 Watt explosion proof LED fixture and allows users to position the light as needed during operations. This switch blade swing arm can be mounted with the light head oriented on the top side or bottom side of the arm, allowing operators to illuminate objects in any location. This swing arm is ideal also for mounting the unit to loading door areas and docks for use as a loading bay or dock light.
Warehouse illuminated by the
WAL-DL-WP60E-48-1227 light head mounted 15` high illuminating a 30` long by 50` wide parking area.
This LED dock light is universal voltage capable and can be operated with standard 110-277 VAC, 50/60Hz without any need for a special ballast. The aluminum body and LED lamp give this light excellent durability and resistance to vibration and impacts. The housing is specially designed to dissipate heat which increases the efficiency and lifespan of the LED luminaries. The LED lamp produces 5,400 lumens with a color temperature of 6000K and a color rendering index of 70 which produces colors and details much more accurately than high pressure sodium or mercury vapor luminaries.
5-15 Straight Blade Plug
L5-15 Twist Lock Plug
L6-15 Twist Lock Plug
UK BS1363 Straight Blade Plug
Intl Schuko 2-Pin Plug
Flying Leads / Pigtail Wires
Wiring and Plug:
This LED swing arm dock light system is equipped with 20` of 16/3 chemical and abrasion resistant SOOW cord that is fitted with an industrial grade cord cap for easy connection to common wall outlets. Plug options include standard 5-15 15 amp straight blade plug for 110V wall outlets with ground, standard 6-15 15 amp straight blade plug for 220-240V wall outlets with ground, NEMA L5-15 15 amp twist lock plug for 125V twist lock outlets, NEMA L6-15 15 amp twist lock plug for 240V twist lock outlets, British BS1363 13 amp fused 3-blade plug for United Kingdom outlets, or a two pin 16 amp rated Schuko plug with ground contact and socket for European outlets up to 250V. Alternatively, we can provide flying leads with no plug for hard wire applications or for operators who prefer to wire in user provided cord caps. Please choose pigtail option below for flying leads with no plug.
High Quality Features
Superior LED Benefits
1. Low power consumption.
1. 50,000 hour lifespan.

Specifications
Lamp Type: LED
Dimensions: W-9" D-3.25" H-6.5" 48"-L
Dimensions: W-9" D-3.25" H-6.5" 48"-L
Weight: 35 Lbs
Voltage: 90-305 Volts AC 50/60hz
Total Watts: 60W
Total Lumens: 5,400
Luminous Efficacy: 90 Lm/W
Lamp Life: 50,000+ Hours
Color Temp: 6000K
Color Rendering Index: >75
Beam Angle: 60° Vertical, 75° Horizontal
Lighting Configuration: Flood Beam
Power Efficiency: >95%
Power Factor: 0.992
Amperage: 0.5A @ 120V, 0.25 @ 240V, 0.22 @ 277V
Ambient Temp Range: -25°C to +60°
Housing Material: Cast Aluminum
Lens Material: Polycarbonate
Mounting: Adjustable Swing Arm Dock Light
Wiring: 20` 16/3 SOOW w/ Cord Csp
Cord Cap: 5-15, 6-15, 5-20, 6-20, L5-15, L6-15, L5-20, L6-20, BS1363, Schuko, or Pigtail
