DCP-6-24V-5P-2X5S Power Converter | DCP-6-24V-5P-2X5S Features |
Line In: 5` SOOW w/ Blunt Cut end - 2-pin Deutch on transformer side | IP67 Rated Waterproof |
Line In Voltage: 100-277VAC @47/63 hz | Overload,Short Circuit,Over Voltage Protection |
Line Out: (2) 5` SOOW cables w/ Blunt Cut ends - Deutch Y on transformer side | UL1012 Compliant |
Line Out Voltage: 24VDC @6.25 Amps | UL60950-1 Compliant |
Watts: 120 | International Lighting Safety Standards Compliant |
AC Input Connector: 1` Pigtail, Straight Blade Plug | Suitable For LED Moving Signs |
DC Output Connector: 1` Pigtail, 2 Pin Deutsch Connector | Power Factor Correction |
Protection: Short Circuit/Overload/ Over Voltage | |
Mounting: Two Screw Slide Notches | |
Operating Temp: -30 / +70C | Toll Free: 1-800-369-6671 |
Efficiency: 92% | Intl: 1-214-616-6180 |
Dimensions: 8.7"-L 2.5"-W 1.5"-D | Fax: 1-903-498-3364 |
Weight:2 Lbs |
The Larson Electronics DCP-6-24V-5P-2X5S Waterproof Power Supply converts commonly used 120 - 240VAC electrical current to 24VDC @6.25 Amps. This converter includes a 5` SOOW with a blunt cut end on the input side and a Y cable with two 5` SOOW cables with blunt cut ends on the output side. This converter can operate with voltages within the 100-277VAC range and converts it to 24VDC, allowing users to use standard AC power to operate equipment like our LED light bars and HID Golights that require 24 Volts DC.
This 120 watt converter comes with 5` of SOOW cable on the input lead and a Y cable with two 5` SOOW cables on the output lead, allowing users to hard wire this unit to high voltage power sources, then connect two 24 volt DC lights or low voltage equipment. The small size and wide input voltage range of this unit make it ideal for operating Larson Electronics LED light bars, Halogen Golights and other equipment that requires 24VDC current indoors or outdoors and anywhere 24 volt DC power is not readily available. THIS WILL NOT WORK WITH THE HID GOLIGHT SPOTLIGHTS (GL-3XXXH-X models) Measuring 8.7 inches long by 2.5 inches wide by 1.5 inches deep, this unit weighs less than one pound and is mounted with two conventional screws via slots that allow removal and repositioning simply by loosening the screws.
|
|||||
Features: The DCP-6-24V-5P-2X5S 120 watt converter features full range, universal AC input capability and can be operated with 100 to 277VAC. The unit converts this AC power input to 120 watt, 6.25 Amp 24VDC output. IP67 rated, this unit is waterproof and suitable for indoor or outdoor applications. Integrally designed protection includes overload, short circuit, over temperature and over voltage safeguards to prevent overheating and unit damage in case of faults or overly heavy current draw. This unit will limit current when an over current condition is encountered and recovers when the condition is removed. This unit will enter hiccup mode under short circuit conditions and recover when the fault is removed. The unit will also shut down when an over temperature condition occurs and recovers automatically when the temperature returns to normal levels. This power converter has a -30 / +70C operating temperature range and is UL UL1012 and UL60950-1 compliant as well as compliant with worldwide safety regulations for lighting. This unit has a 92% conversion efficiency and is suitable for use with moving LED signs and similar LED equipment. These units also feature Power Factor Correction, adjustable output current range from 3.15~ 6.3A either through the output cable or internal potential meter and have an input frequency range of 47 ~ 63Hz. NOTE: In order to obtain the best performance and the longest operational life from these units, it is recommended that you do not exceed 75% of the unit’s output amperage. To determine if this converter suits your desired application, add together the total wattage of the equipment you intend to use with this unit and divide this total by 24 volts to find the total amperage draw that will be placed upon the converter. For example, if you are using our LEDP10W-60E 60 watt LED light, 60 watts divided by 24 volts is 2.5 amps. This would mean the DCP-6-24V-5P-2X5S is well suited as it would run at just under 50% capacity to produce the necessary 2.5 amps. Running these units at 100% of their capacity can create excess heat and lead to shortened converter life. |
