Explosion Proof Control Station - C1D1 - (16) Holes, (10) PLs, (1) PB - (2) Hubs - N3R
Explosion Proof Control Station - C1D1 - (16) Holes, (10) PLs, (1) PB - (2) Hubs - N3R
EPCS-12.12.8-10XPLR-1XMSPB-16XT-1.25XN-0.75S Explosion Proof Control Station | Features/Ratings |
Listing:Â NRTL Listed for United States and Canada | Class I, Divisions 1 & 2, Groups B**, C, D |
Internal Dimensions: 12" (305mm) L x 12" (305mm) H x 8" ( 203mm) D | Class I, Zones 1 & 2, Groups IIB+H2, IIA |
External Dimensions: 16.38'' (416.05mm) L x 16.38'' (416.05mm) H x 10.69'' (271.53mm) D | Class II, Divisions 1 & 2, Groups E, F, G |
Available Dimensions for Devices: 11.37'' (288.8mm) L x 11.37'' (288.8mm) H x 8.00'' (203.20mm) D | Class III, Divisions 1 & 2 |
Weight: - | NEMA 3R, 4, 7, 9 |
Maximum Conduit Size: 5€ NPT | NRTL Certified to UL 886 |
Available Holes for Operators on Lid: 16 (4 rows of 4) | NRTL Certified to UL 698 |
Pilot Lights: (10) 24V - Red | NRTL Certified to UL 1203 |
Push Buttons: (1) Momentary, 24V - Black | NRTL Certified to CSA C22.2 No 30 |
Total Hub Quantity: (2) | Â |
Lid (Top) Hubs: 0 | Â |
North Side Hubs: (1) 1 1/4" NPT | |
South Side Hubs: (1) 3/4" NPT | |
East Side Hubs: 0 | **Conduit seals required within 18" for Group B applications |
West Side Hubs: 0 | |
Bottom (Back/Base) Hubs: 0 | Â |
Conduit: Operator Provided | |
Operating Window: N/A | |
Hinges Included: No | |
Hinges Material: N/A | |
Internal Mounting Pan Included: N/A | |
Internal Mounting Pan Taps: N/A | |
Internal Mounting Pan Material: N/A | |
Internal Mounting Pan Dimensions: N/A | |
Internal Grounding Lug: N/A | |
Breather Plug: N/A | |
Drain Plug: N/A | |
Suggested Operator Series: Long Length | |
Ambient Operating Temp Range: -30° C to +85°C | |
Operating Temp Rating: T5/T6 Rated | |
Enclosure Material: Copper Free Cast Aluminum (less than 4/10 of 1%) | |
Hardware Material: Zinc Plated Steel | |
Enclosure Finish: Aluminum Lacquer Paint; Custom Available | |
Mounting: Surface Mount Legs | |
Mounting Leg Height: 0.25" | |
Mounting Dimensions Height: 6.94'' (176.28mm) Center to Center | Toll Free:Â 1-800-369-6671 |
Mounting Dimensions Width: 14.94'' (379.48mm) Center to Center | |
Shipping Weight: - | |
Shipping Dimensions: 48"L x 48"W x 21"H | |
*All grounding shall comply with state and local codes and meet the minimum requirements of the National Electronic Code section 250* |
The EPCS-12.12.8-10XPLR-1XMSPB-16XT-1.25XN-0.75S from Larson Electronics is an Explosion Proof Control Station for use in Class I and II, Divisions 1 and 2 rated facilities. Ten red pilot lights, one momentary black push button and sixteen holes on the lid for operators are available on the system. Constructed of non-sparking aluminum, the unit features two hubs for completing wiring connections.
*PLEASE NOTE: ANY FREE SHIPPING OFFERS DO NOT APPLY TO EXPLOSION PROOF ENCLOSURES*
The EPCS-12.12.8-10XPLR-1XMSPB-16XT-1.25XN-0.75S explosion proof control station is made of cast aluminum, equipped with steel bolts and includes a weatherproof gasket for a NEMA 3R / NEMA 4 protection rating. This hazardous location device is NEMA 7 (Groups B, C, and D) and NEMA 9 (Groups E, F, and G) rated. The internal cavity of this flameproof system measures 12" in length by 12" in width by 8" in height. A backplate is available for this unit at an extra cost.
The EPCS-12.12.8-10XPLR-1XMSPB-16XT-1.25XN-0.75S has a maximum input/output conduit size of 5" NPT. Operators may access the following hubs on the unit: (1) 3/4" NPT and (1) 1 1/4" NPT. The lid of the enclosure allows for a maximum of 16 long operator devices (switches, push buttons, indicator lights, etc.) in a configuration of 4 rows of 4. There are ten 24V red pilot lights, as well as one momentary 24V black push button on the system. Customized boxes with selected operators can be factory installed at customer's request.
|
