Larson Explosion Proof 10 Foot SOOW Extension Cord - 20 amp continuous service - 12/3 SOOW

Larson ElectronicsSKU: PL3-EPEXC-10-12-3-20A
filler

Prix:
Prix réduit$2,852.00
 Plus de moyens de paiement

Description

PuriLite suggests you place an order directly with us for large Larson orders due to the potential customization requirements. Please call us at 1(647) 254-9757 to place your order. If you prefer to place your order online, a PuriLite agent will be in touch with you to discuss any custom options.
Made in the USA
Larson Electronics 10` Explosion Proof 20 Amp Extension Cord
The Larson Electronics EPEXC-10-12-3-20A Explosion Proof extension cord allows operators to safely extend the range of their explosion proof light or equipment cords beyond the boundaries of the hazardous work area. These units are constructed of 10 feet of 12/3 SOOW explosion proof cord rated at 20 amps of continuous service. The cord is chemical and abrasion resistant and comes with an explosion proof receptacle installed on one end and an explosion proof plug installed on the other end. We also include an extra matching plug for operators to attach to their equipment which allows them to avoid any issues with plug and receptacle equipment compatibility with this cord.
The plugs on these units are of a twist lock design. In order for a secure and working connection to take place, the operator must insert the plug and twist until it locks into place. This ensures a safe seal is made before any sparks from electrical contact can take place. To ensure the highest safety, operators should make connections outside of the hazardous area.
These explosion proof extension cords are preconfigured in 125V (left) or 250V (right). Each unit is equipped with a 20 amp explosion proof cord cap and rated for 20 amps of continual service. The outlets are a twistlock design. The deep recessed contacts in the receptacle housing prevents ordinary and wet location plugs from activating the explosion proof outlets.
125V 5-20P Explosion Proof Straight Blade Plug
250V 6-20P Explosion Proof Straight Blade Plug
125V 5-15/20 Explosion Proof Outlet
Outlet accepts 15A and 20A Explosion Proof Plugs
Outlet accepts 6-15P and 6-20P Explosion Proof Plugs
Inter-Compatibility:
The plugs on these cords will work with non-explosion proof standard receptacles (NEMA 5-15R, 5-20R, or 6-20R) and standard wall outlets, however, they must be used with explosion proof rated outlets to retain their explosion proof rating. The included plugs and receptacle are cross-interchangeable with Crouse Hind™ part# ENPENP5151 plugs and receptacles, Hubble-Killiark part# UGP-20231 ACCEPTOR plugs and receptacles, and Appleton U-Line ECP-2023 plugs and EFS150-2023 receptacles . Any equipment requiring these plugs should work with these cords. Due to possible manufacturer changes we cannot guarantee interchangability although we have made every effort to ensure cross compatibility correctness.
Suggested Applications:
Manufacturing, Industrial, Warehouse, Lighting, Explosion Proof Light Fixtures, Grinders, Wet areas or Locations Where Combustible Dust is Present.

Specifications
Amp Rating:  20 amp Continuous Service

Dimensions: Cord length-10 Feet  Plug-2.78"-L 1.75"-W 3"-W X 5.69"-D X6.13"-H
Configuration: 2 Pole 3 Wire 2 Pole 3 Wire
Suitable Plug Cable Diameter: .538” to .639”
Receptacle Specs:
Voltage: 125V AC @ 20 amps
Configuration: 2 Pole 3 Wire 2 Pole 3 Wire
Materials:  Copper Free Aluminum
Dimensions: Cord length-10 Feet  Plug-2.78"-L 1.75"-W 3"-W X 5.69"-D X6.13"-H
Mating Plugs: ****EPP-15A, EPP-20-A****
Finish: Epoxy Powder Coat
