Explosion Proof Control Station - 12" x 12" x 6" - Six Switches - Class 1 Division 1

LARSON ELECTRONICSSKU: PL3-EXP-CS-12.12.6-3XMS-1X3PS-1X2PS-1XPBS
filler

Prix:
Prix réduit$13,394.00

Description

Specifications / Additional Information
EXP-CS-12.12.6-3XMS-1X3PS-1X2PS-1XPBS Explosion Proof Enclosure Features/Ratings
Internal Dimensions: 12€H x 12€W x 6€W Class 1 Division 1 Explosion Proof
Weight: Class 2 Division 1 Explosion Proof
Mounting: Surface Mount
Hubs: (2) 3/4" NPT
Momentary Switches: (3) Black push button Toll Free: 1-800-369-6671
3-Position Switches: (1) Black Intl: 1-214-616-6180
2-Position Switches: (1) Black
Emergency Switches: (1) Red Mushroom Push/Pull
*All grounding shall comply with state and local codes and meet the minimum requirements of the National Electronic Code section 250*
' Product Overview '
Made in the USA The Larson Electronics EXP-CS-12.12.6-3XMS-1X3PS-1X2PS-1XPBS explosion proof control station provides operators with a Class 1 and 2, Division 1 and 2 cast aluminum control station to control electrical equipment within hazardous locations. This explosion proof enclosure is ideal for indoor or outdoor applications where flammable vapors, gases, or dusts exist or stand the potential to exist. *PLEASE NOTE: ANY FREE SHIPPING OFFERS DO NOT APPLY TO EXPLOSION PROOF ENCLOSURES* The EXP-CS-12.12.6-3XMS-1X3PS-1X2PS-1XPBS explosion proof control station is constructed of cast aluminum, is equipped with stainless steel hinge and bolts, and includes a watertight gasket for a NEMA 4X protection rating. The internal cavity of this flameproof enclosure measures 12" in length by 12" in width by 6" in height. Mounting is provided by four ears, two per side of the enclosure. This unit is equipped with three momentary push button switches, one 3-position switch, one 2-position switch, and one emergency push button switch. Two 3/4" NPT hubs allow operators to bring power and cabling into this control station. External seals are required. LarsonElectronics.com can build enclosures to your specifications. If this model does not meet your needs, please contact us at 1-800-369-6671 or .
