Explosion Proof Control Station - C1D1 - 12" x 12" x 6" - (6) Switches - (4) 1" NPT Hubs
Explosion Proof Control Station - C1D1 - 12" x 12" x 6" - (6) Switches - (4) 1" NPT Hubs
| EXP-CS-12.12.6-3XMS-1X3PS-1X2PS-1XPBS-M1 C1D1 and C2D1 Rated Enclosure | Features/Ratings |
| Listing: NRTL Listed for United States, Canada | Class I, Division 1 & 2 |
| Unit Type: Explosion Proof Enclosure | Class II, Division 1 & 2 |
| Internal Dimensions: 12€ÂH x 12€ÂW x 6€ÂW |  |
| Weight: - | Â |
| Momentary Switches: (3) Black Push Button | |
| 3-Position Switches: (1) Black | Â |
| 2-Position Switches: (1) Black | |
| Emergency Switches: (1) Red Mushroom Push/Pull | |
| Mounting: Surface Mount | |
| Hub Qty: 4 | |
| Hub Sizes: (4) 1" NPT | |
| Hub Locations: (2) 1" NPT @ North Side, (2) 1" NPT @ South Side | |
| *All grounding shall comply with state and local codes and meet the minimum requirements of the National Electronic Code section 250* |
| The Larson Electronics EXP-CS-12.12.6-3XMS-1X3PS-1X2PS-1XPBS-M1 Explosion Proof Control Station provides operators with a Class I and II, Divisions 1 and 2 cast aluminum control station to control electrical equipment within hazardous locations. This explosion proof enclosure is ideal for indoor or outdoor applications where flammable vapors, gases, or dusts exist or stand the potential to exist. *PLEASE NOTE: ANY FREE SHIPPING OFFERS DO NOT APPLY TO EXPLOSION PROOF ENCLOSURES* The EXP-CS-12.12.6-3XMS-1X3PS-1X2PS-1XPBS-M1 explosion proof control station is constructed of cast aluminum, is equipped with stainless steel hinge and bolts, and includes a watertight gasket for a NEMA 4X protection rating. The internal cavity of this flameproof enclosure measures 12" in length by 12" in width by 6" in height. Mounting is provided by four ears, two per side of the enclosure. This unit is equipped with three momentary push button switches, one 3-position switch, one 2-position switch, and one emergency push button switch. A total of four, 1" NPT hubs allow operators to bring power and cabling into this control station. The hubs are located at the following: two, 1" NPT @ north side and two, 1" NPT @ south side. External seals are required. |
