8000W Single Output AC/DC Power Supply - 335A - 120-240V AC Input to Single 24V DC Output - NEMA 3R
8000W Single Output AC/DC Power Supply - 335A - 120-240V AC Input to Single 24V DC Output - NEMA 3R
| IND-DCP-FC-SP-8KW-24V-N3R Single Output Power Supply | Ratings |
| Unit Type: AC/DC Power Supply (Enclosed) | Built-in DC Fan |
| Dimensions: 26.4"-L x 29.30"-W x 13.73"-H | Remote Sense |
| Weight: - | Â |
| Input Voltage: 120-240 V AC | Â |
| Output Voltage: 22-28 V DC (Programmable) | Â |
| Amps: 335A | Â |
| Rated Power: 8,000W | Â |
| Power Factor: 0.95/230 V AC @ Full Load | Â |
| Efficiency: 90% | Â |
| Leakage Current: < 2.0mA/240 V AC | Â |
| Ripple/Noise: 150mVp-p | Â |
| Protection: Overload (100-112% Rated Output Power), Over Voltage, Over Temperature, Short Circuit | |
| Current Sharing: Up to 9,000W or 2+1 Units | Special Orders - Requirements |
| Aux Power: 12 V @ 0.1 A (For Remote Control) | |
| Alarm Signal Output: Power Ok Signal | Toll Free:Â 1-800-369-6671 |
| Operating Temp: -20°C to +70°C | Intl: 1-214-616-6180 |
| Materials: Metal | |
| Mount: Surface/Chassis Mount |
| The IND-DCP-FC-SP-8KW-24V-N3R from Larson Electronics is a Single Output AC/DC Power Supply that provides accurate voltage control and power management features for industrial operations. This 335-amp unit is compatible with 120-240V AC and provides a programmable output voltage range of 22-28 V DC. Equipped with protective functions, the device features remote sensing and remote control (on/off) capabilities. A built-in DC fan keeps the power supply cool during use. The IND-DCP-FC-SP-8KW-24V-N3R is a compact AC/DC power supply for industrial facilities. The single output unit accepts input voltage ranges of 120-240 V AC and offers a programmable output voltage range of 22-28 V DC. This 335-amp device is rated at 8,000W and contains remote on/off control functions (via 12 V @ 0.1 A aux power). Protective features include overload, over voltage, over temperature, and short circuit. Capable of reaching 90% efficiency, current sharing is possible up to 9,000W or 2+1 units. This enclosed unit is constructed of metal and features a built-in DC fan for active cooling. Operators can mount the device on chassis or surfaces. Applications: Industrial sites, factory control, automation, laser machines, manufacturing, voltage control, power management, digital broadcasting, RF applications, computerized systems and more. |
