1.6kW Portable Stepdown Transformer - 220/240V to 110V 1PH - (2) 5-10P/5-15P 110V Receptacles

LARSON ELECTRONICSSKU: PL3-MT-VCT-HD-220V-1.6KVA-110V-2X-2M
filler

Prix:
Prix réduit$2,376.00

Description

Specifications / Additional Information
MT-VCT-HD-220V-1.6KVA-110V-2X-2M Portable Power Distribution Features/Ratings
Unit Type: Portable Stepdown Transformer Self-cooling
Dimensions: 13.38" x 8.66" x 6.69" Portable Handle
Weight: 22 lbs
Input Voltage: 220-240V 1PH 50/60 Hz
Watts: 1600W
Output Voltage: 110V 1PH 50/60 Hz
Output Receptacles: (2) 5-10P/5-15P - 110V
Circuit Breaker: (1) Primary Circuit Breaker/On-Off Switch @ Front
Operating Temp: –10°C - +40°C
Humidity: 5-95% w/o Condensation
Storage: –20°C - +60°C (No Dust, Corrosive Gas, Direct Sunlight)
Mount: Standalone or Portable Handle
Wiring: 2M Flexible Power Cable w/ Cord Cap
Cord Cap Options: BS1363 or Schuko
' Product Overview '
Made in the USA The Larson Electronics MT-VCT-HD-220V-1.6KVA-110V-2X-2M Portable Stepdown Transformer provides operators the ability to safely tap into and distribute 220-240V AC power from a variety of sources including generators and direct grid power. This unit, which features a portable handle for seamless transportation, contains two, 5-10P/5-15P 110V receptacles and a two-meter power cord with cord cap. The MT-VCT-HD-220V-1.6KVA-110V-2X-2M is a stepdown voltage converter transformer for powering compatible equipment at industrial work sites. A sturdy power cord with cord cap brings in 220-240V single phase 50/60Hz into the 1600-watt transformer, which converts input power to 110V single phase 50/60 Hz. Operators are provided access to the following 110V receptacles on the output side of the stepdown transformer: (2) 5-10P/5-15P. One circuit breaker on the primary side provides overload protection, which also doubles as an on-off switch. The components are convienently located at the front of the device, above the receptacles. This self-cooling unit is equipped with an IP20-rated enclosure for protection. Ideal operating temperature range includes –10°C - +40°C. The MT-VCT-HD-220V-1.6KVA-110V-2X-2M can be used on flat, stable surfaces. This unit comes with a 2-meter power cord for completing input connections. Cord cap options inlcude: BS1363 or Schuko. Applications: Power distribution, appliances, industrial equipment, voltage conversion and more.
