LiPo Charger Basic - Mini-USB

SparkFunSKU: PL4-PRT-10401
filler

Prix:
Prix réduit$49.99

Description

If you need to charge LiPo batteries, this simple charger will do just that. It is designed to charge single-cell Li-Ion or Li-Polymer batteries. Check the datasheet below to see if it will work with your battery.

The board incorporates a charging circuit, status LED, connector for your battery (JST-type used in the batteries we carry), and a mini-USB connector. However, we do not recommend this charger with a 110mAh battery.

**Note:** This version uses a mini-USB cable. We also have this charger with a micro-USB connection as well.

**Features:**

* 34.1x13.2mm

**Documents:**

* [Schematic](http://www.sparkfun.com/datasheets/Prototyping/Batteries/LiPo-Charger-Basic-MiniUSB-v10.pdf)
* [Eagle Files](http://www.sparkfun.com/datasheets/Prototyping/Batteries/LiPo-Charger-Basic-MiniUSB-v10.zip)
* [Datasheet](http://cdn.sparkfun.com/datasheets/Components/General%20IC/33244_SPCN.pdf) (MCP73831T)
* [GitHub](https://github.com/sparkfun/Lipo_Charger_Basic-miniUSB/tree/V_1.0)
