Chief CMS491CP2 Ceiling Mount for Projector - White - TAA Compliant - 45 kg Load Capacity
Chief CMS491CP2 Ceiling Mount for Projector - White - TAA Compliant - 45 kg Load Capacity
Chief CMS491CP2 Ceiling Mount for Projector - White - TAA Compliant - 45 kg Load Capacity
The CMS491CP2 conceals AV equipment above a 2' X 2' ceiling tile and supports a 1.5" NPT column drop for mounting projectors within the same tile grid providing a clean professional look for classrooms and conference rooms.
Includes a high-performance, dual gang housing, isolated ground, dual receptacle outlet featuring the SurgeX ® non-sacrificial multi-stage filtration and surge protection system. This protects equipment from disruptive high frequency noise and damage caused by power disturbances.
Chief's powered solutions were co-developed with SurgeX, a brand of AMETEK ® Electronic Systems Protection.
Column not included, must be purchased separately.
- Optimal pipe flexibility within the tile helps with less reliance on image correction improving image quality
- Drop carriage door improves accessibility and serviceability providing full access to equipment
- Detachable power housing can be pre-installed with electricians on site and assembled to the storage box at a later time
- Inside the plenum box or facing the room
- Up to 2 single gang or 1 dual gang outlet
- 4 nested knockouts for 1-1/4", 1", & ½" diameter conduit
- Built in ventilation
- AV tray supports a variety of AV components
- Ships with 1 shelf, 2nd shelf sold separately see CMSUNV1
- Overall weight capacity 100 lbs (45 kg)
- 50 lbs (22 kg) for projector ceiling plate
- 25 lbs (11 kg) per shelf location
- Ships with speed connect installation hardware
- Lightweight construction, one man installation
- Plenum rated, UL approved in accordance to 2043
- TAA Compliant
| Limited Warranty | 1 Year |
| Product Type | Ceiling Mount |
| Manufacturer Part Number | CMS491CP2 |
| Manufacturer Website Address | http://www.legrand.com |
| Manufacturer | Legrand Group |
| Product Model | CMS491CP2 |
| Product Name | 1' x 2' Plenum Rated Storage Box and Column Drop with 2-Gang Filter & Surge |
| Product Series | CMS |
| Brand Name | Chief |
| Device Supported | Projector |
| Maximum Load Capacity | 45 kg |
| Package Contents |
|
| Country of Origin | United States |
| TAA Compliant | Yes |
| Color | White |
| Height | 8" (203.20 mm) |
| Width | 12.97" (329.44 mm) |
| Depth | 23.67" (601.22 mm) |
