Advantech IDS-3212R-45SVA1E 12.1" LCD Touchscreen Monitor - 4:3 - 35 ms - 12.00" (304.80 mm) Class - 5-wire Resistive - 800 x 600 - SVGA - 16.2 Million Colors - 450 cd/m‚² - LED Backlight - DVI - USB - VGA - RoHS - 2 Year

AdvantechSKU: PL5-IDS-3212R-45SVA1E-575VVP-EN
filler

Prix:
Prix réduit$633.99
 Plus de moyens de paiement

Description

Advantech IDS-3212R-45SVA1E 12.1" LCD Touchscreen Monitor - 4:3 - 35 ms - 12.00" (304.80 mm) Class - 5-wire Resistive - 800 x 600 - SVGA - 16.2 Million Colors - 450 cd/m² - LED Backlight - DVI - USB - VGA - RoHS - 2 Year

Introduction

The Advantech IDS-3212 Embedded Industrial Panel Mount Monitor series offers flexible options for LCD, touchscreen, signal interface and chassis mounting. The series with standard integrated frame design, supports rear and VESA mounting which brings the benefits of easy installation, and flexibility for different applications.
Features
  • 12.1" SVGA / XGA LCD panel with LED backlight for 20% power savings, and environmental protection
  • -20° C ~ +60° C wide range operating temperature
  • 5-wire resistive touch screen solution or 3mm tempered smudge resistant protected
  • Combo touch interface, both RS-232 and USB
  • Dual signal interface with VGA & DVI
  • Standard integrated frame
  • Versatile mounting method for rear mounting and VESA mounting
  • Anti-Reflective treatment (optional)
  • Ultra high brightness solution of 1200 cd/m2 for utdoor applications (optional)
Operating Power Consumption 36 W
Touchscreen Type 5-wire Resistive
Limited Warranty 2 Year
Package Contents
  • IDS-3212R-45SVA1E LCD Touchscreen Monitor
  • 1 x M Cable USB-A(M)/USB-A(M) 180CM
  • 1 x VGA cable 15P(M) 180 cm
  • 4 x Clampers
  • 4 x Screws of clamper M4_25L
  • 1 x Cable clamp
  • 1 x Screw of cable clamp
  • 1 x Cable tie
  • USB Cable
Environmentally Friendly Yes
Environmental Certification RoHS
USB Yes
DVI Yes
VGA Yes
Number of USB Ports 1
Product Type LCD Touchscreen Monitor
Manufacturer Part Number IDS-3212R-45SVA1E
Manufacturer Website Address http://www.advantech.com
Manufacturer Advantech Co., Ltd
Product Model IDS-3212R-45SVA1E
Product Name IDS-3212R-45SVA1E LCD Touchscreen Monitor
Product Series IDS-3212R
Brand Name Advantech
Brightness 450 cd/m²
Color Supported 16.2 Million Colors
Maximum Resolution 800 x 600
Native Contrast Ratio 700:1
Weight (Approximate) 2.50 kg
Height 10.33" (262.40 mm)
Width 12.74" (323.70 mm)
Depth 1.44" (36.50 mm)
VESA Mount Compatible Yes
VESA Mount Standard 100 x 100
Aspect Ratio 4:3
Response Time 35 ms
Mount Type Panel Mount
Viewable Screen Size 12.1"
Screen Mode SVGA
Backlight Technology LED
Screen Size Class 12.00" (304.80 mm)
